GoodWe A-ES 9.6kW Inverter with GoodWe Lynx FH-US High Voltage Battery — UL 9540 Closed-Loop Bundle (9.6/12.8/16/19.2/38.4kWh)(APsmart RSD)

Back To Shop

GoodWe A-ES 9.6kW Inverter with GoodWe Lynx FH-US High Voltage Battery — UL 9540 Closed-Loop Bundle (9.6/12.8/16/19.2/38.4kWh)(APsmart RSD)

GoodWe A-ES 9.6kW Inverter with GoodWe Lynx FH-US High Voltage Battery — UL 9540 Closed-Loop Bundle (9.6/12.8/16/19.2/38.4kWh)(APsmart RSD)

GoodWe A-ES 9.6kW Inverter with GoodWe Lynx FH-US High Voltage Battery — UL 9540 Closed-Loop Bundle (9.6/12.8/16/19.2/38.4kWh)(APsmart RSD)

SKU: N/A Category: Brand:

Description

Overview

Tech Specs

GoodWe A-ES 11.4kW 211-264 47.5A Hybrid Inverter
AC Output Voltage 211 to 264V @240V
Max. Input Power 15000W
Efficiency 97.6%
MPPT Voltage Range 550VDC
Max Continuous Charging Current 50A
Battery Technologies Li-ion
Battery Voltage Range 80V ~ 495V
BMS Communication RS485, CAN
Enclosure NEMA Type 4X
Operating Temperature -31°F ~ +140°F (-35°C ~ +60°C)
Noise <40 dB
Dimension 16.3 × 31.1 × 6.9 inch
Weight 70.5lbs
Warranty 10 Years
Certificate UL1741 SA, California Rule 21, HECO Rule 14, IEEE 1547, IEEE 1547.1,UL 1741, CSA 22.2 No. 107-01, UL 1998, UL1699B,FCC part15 CLASS B



GoodWe Lynx FH-US 3.2kWH 256V LiFeO4 Battery
Nominal Voltage 256V
Operating Voltage Range 228V ~ 288V
Energy 12.8KWH
Nominal Power (kW) 8.96kW
Relative Humidity ≤95%
Nominal Dis- / Charge Current (A) 35
Ingress Protection Rating IP65
Operating Temperature Charge: +32°F ~ +122°F (0°C ~ +50°C); Discharge: +5°F ~ +122°F (-15°C ~ +50°C)
Installation Ground-Mounted
Dimension 23.6 × 35.6 × 15 inch
Weight 384.71lbs
Warranty 10 Years
Certificate UL1973, UL9540A-2019,FCC part 15,UN38.3



Automatic Transformer
Rated Voltage 120/240V Split Phase
Max. Continuous Rated Power (L-N) (VA) 4800V
Rated Frequency 60Hz
Max Continuous Output Current Per Phase@120V 40A
Split Phase Imbalance Current@Rated Power 40A
Thermal Protection YES
Operating Temperature Range -31°F ~ +140°F (-35°C ~ +60°C)
Relative Humidity 0 ~ 95%
Ingress Protection Rating Type 4X
Mounting Method Wall Mounted
Noise Emission (dB) <25db
Weight 48.5lbs
Dimension 13.6 × 10.9 × 6.9 inch
Warranty 10 Years
Certificate UL1741

Supports

Click here

Additional information

Model

KG963203(9.6kW INV+ATX+PCU+9.6kWh BAT), KG963204(9.6kW INV+ATX+PCU+ 12.8kWh BAT), KG963205(9.6kW INV+ATX+PCU+16kWh BAT), KG963206(9.6kW INV+ATX+PCU+19.2kWh BAT), KG963212(9.6kW INV+ATX+2PCUs+38.4kWh BAT)
